NASCJ Automatic Steep wave impulse voltage generator 南澳電氣NASCJ全自動陡波沖擊電壓發生器試驗裝置
產品簡介
南澳電氣NASCJ全自動陡波沖擊電壓發生器試驗裝置 主要用于高壓線路B型線路絕緣子和高壓線路用有機復合絕緣子等試品進行陡波沖擊電壓試驗，檢驗絕緣性能。
南澳電氣NASCJ全自動陡波沖擊電壓發生器試驗裝置 產品特性
1、成套裝置配套完整；
2、本體配套調波電阻和弱阻尼電容分壓器可產生標準雷電波和標準操作波，再配套多球截波裝置可產生標準雷電截波；
3、調波方便，操作簡單，同步性能好，動作可靠；
4、壓縮型快速電阻分壓器方波響應特性好；
5、采用恒流充電自動控制技術，自動化程度高，抗干擾能力強；
6、可采用沖擊波形數字分析系統和沖擊電壓試驗數據微機在線處理系統，大大提高沖擊電壓試驗技術水平和試驗效率。
南澳電氣NASCJ全自動陡波沖擊電壓發生器試驗裝置 產品參數
600kV配套線路絕緣子陡波陡化裝置和快速電阻分壓器可產生波頭時間為100～200ns陡波沖擊波；750kV或900kV、1200kV沖擊電壓發生器本體配套復合絕緣子陡波陡化裝置和快速電阻分壓器可產生陡度大于1000KV/us陡波沖擊波和100～200ns陡波沖擊波，技術指標符合國家標準和IEC標準的規定，主要技術性能在國內處于領先地位，達到國際同類產品的領先水平。
Product introduction
NASCJ Steep wave impulse voltage generator is mainly used for high voltage lime B-type insulator and high voltage line with organic composite insulators to test steep wave impulse voltage. And test the insulation performance.
The Characteristics of the products
(1) Complete sets of equipment.
(2) The impulse voltage generator configured with modulated wave resistance and weakly damped capacitive divider can produce standard lightning wave and standard operating wave, and if it configured with multi-ball chopping device can produce standard chopped lightning impulse;
(3) Convenient modulated wave, simple operation, good synchronizing performance and reliable operation;
(4) Good characteristics of square wave response of compact fast resistor divider.
(5) Adopting constant-current charging automatic control technology, which is high automation and strong anti-interference ability.
(6) System can adopt the digital analysis system for shock wave and computer online processing system for impact voltage test data, which greatly improve the technical level and test efficiency of impulse voltage tests.
The parameters of the products
The 600kV steep wave impulse voltage generator configured with line insulator steep wave steepness device and rapid resistor divider can produce steep wave shock wave which wave front time is 100 ~ 200ns; The 750kV, 900kV or 1200kV of steep wave impulse voltage generator configured with composed insulator steep wave steepness device and rapid resistor divider can produce steep wave shock wave which gradient is greater than 1000 kv/us and the wave front time is 100 ~ 200ns. The technical indicators is in line with national standards and IEC standards, has passed the ministerial appraisal, the main technical performance is in the domestic leading position, has reached the advanced level of international similar products.
