供應1X8MEMS光開關

  • 這真不是您需要的產品？
  • 品　　牌：
  • 主要規格：
  • 用　　途：
    • OVERVIEW 1x8 MEMS switch is a very fast opto-mechanical switch working over both telecom wavelength windows from 1240 nm to 1640 nm. The highly reliable switching mechanism is based on micromechanical mirrors and features below 1 ms switching time and only 1.5 dB insertion loss. The miniature package withstands rugged environments and is well suited for direct mounting on printed circuit boards. FEATURES ??reliable ??1.0 dB insertion loss ??1 ms response time ??60 dB crosstalk ??non-latching APPLICATIONS ??Source Selection ??Protection Switching ??Monitoring ??Wavelength provisioning DESCRIPTION The non-latching 1x8 switch modules are fast and reliable switches designed for single mode fiber instrumentation and communication equipment. The device is based on the latest silicon MEMS technology and uses micro-mechanical mirrors to redirect the light. The absence of fatigue and wear-out allows to achieve a constant switching quality even after billions of actuation cycles. The switch features fast switching below 1 ms and high crosstalk attenuation above 60 dB. Repeatability is better than 0.01 dB. The switch is powered by a 5 V supply voltage. A 5 V TTL or CMOS drive signal is used to control the switching state. TECHNICAL SPECIFICATIONS Unit Min Typ Max Wavelength Range nm 1240 1640 Insertion Loss dB 1.2 2.0 Crosstalk dB 75 60 Back reflection dB 55 50 Polarization Dependent Loss dB 0.12 Switching Time ms 0.5 1 Switching Voltage V 5 Fiber Pigtail mm 9/125/900 Durability cycles 23 Billion Power Consumption mW 10 50 Operation Temperature °C 0 70 Storage Temperature °C -40 85 Size (L x W x H) mm 76 x 93 x 9.5 ELECTRICAL SPECIFICATIONS Supply: 4.5 - 5.5 V, 10 mA max S1 – S3: CMOS or TTL levels, 0 mA Optical Port Selection
    南寧市科毅光通信科技有限公司

    劉喬鳳

    • [聯系時請說明來自檢測通]
    • 聯系方式：

    • 請點擊查看電話

    • 地址：
    • 南寧高新區西十路26號
